SONY IMX214
Model
FL0214Temperature class
-20℃~65℃Ean
6971390274613Price
$ 440Binocular Camera Module SONY IMX214 CMOS, Sensor 13 Million Pixels MIPI Interface, Standard FMC LPC Interface
CMOS Image Sensor Chip
SONY IMX214
Resolution
13Mega-Pixel （4208 × 3120）@30fps, 4K / 2K@30fps, 1080p@60幀
Output Video Format
RAW10/8, COMP8/6
Interface
CSI-2 serial Data Output (MIPI 4 lane, compatible D-PHY standard V1.1)
Viewing Angle
80.7° ± 3° (Diag)
Focusing Mode
Motor Auto Focus
Focusing Distance
3.94 inch ~ infinity
Size Dimension
2.72 inch x 2.99 inch
Supporting FPGA Board
with FMC Connectors
Documents Provided
Schematic, FPGA Testing programs
FMC Interface
The warranty period of all products sold is 12 months, of which FPGA chips and LCD screens are wearing parts and are not covered by the warranty. All accessories and gifts are not covered under warranty.
